KS-5000
Rotary type pouch cutter
This device notches and cuts each pouch (multiple pouch units are also possible) of the continuous packaging with a high-speed rotary cutter.
Drawing
Labor saving effects
Manual work
approx. 30 pouches/minAfter installing the device
approx. 500 pouches/min
Features
- Equipment capacity: 500 pouches/min
- The device can cut, perforate and notch large pouches.
- Continuous feeding is realized by matching the cutter blade rotation speed with the pouch feed speed when cutting the pouches. Even when operated at a high speed, smooth movement gentle to pouches is made possible.
- Cutting and perforation are performed with a single cutter blade, improving the accuracy of cutting and perforation.
- The cutter unit and perforation unit feature an angle adjustment function that corrects diagonal cuts.
- The notch position and depth can be adjusted during operation. It is also possible to insert notches diagonally to cut the corners easily.
Specification
| Equipment capacity |
500 pouches/min (maximum) *The longer the pouch length is, the lower the capacity will become. *The maximum capacity will vary depending on the conditions of the packaging materials and contents. |
|---|---|
| Pouch specification |
Width 65 – 130mm Length 45 – 230mm Thickness 20mm (maximum) |
| Power supply | 3φ AC200V 50/60Hz 2.5 kVA |
| Weight | Approx. 300kg |
