align
LPC

Excludes all "differences" thoroughly, excludes together with the wastefulness of resources.
It is " arranging" partner of the trust.

Achieving High Precision Line Position Control Using Cutting Edge Technology.

LPC is the name given to our company's Web Guide System,taking the first letters of Line Position Control.
The LPC Web Guide System was developed in 1953 and since its commercialization,It has been utilized in a wide variety of fields such as the paper and film industries,and the rubber and textiles industries.
We are constantly putting effort toward using the leading technology for the development of new products,and we aim to create a complete lineup in order to better respond to our customers' needs.

LPC Basic System >>
Unwinding Guide System >>
Winding Guide System >>
Winding Middle Guide System >>
LPC Products >>
LPC Composition Apparatus >>
LPC Control Board >>
LPC Detector >>


LPC basic system
unwinding guide system

A meander control is done while the cart of unwinding moves to either side for the web to run based on the position of the beforehand installed detector.

go top

winding guide system

A meander control is done while the cart of winding moves to either side for the web to run based on the position of the beforehand installed detector.

go top

winding center guidance system

It is the system to arrange immediately before the position which needs the meander control of the web in the middle from the unwinding to the winding about the processing line of the web and to control it.

go top

LPC Products
LPC Web guide system control device

Allowing optimum control of the web.

The LPC Web guide system is made up of detector,a controller and a driver. Please choose the controller according to the detector and driver used.

CONTROL DEVICE

* PW-1000
* PW-1300
* PW- 650
* PW- 800
* PWN-800
* PWN-1000

go to top

LPC guide system sensor

Precise detection of web edges or line marks.

Precise detection of web edges or line marks.
Detectors can be basically divided into optical reflection types,optical transmission types and ultrasonic transmission types.
Reflection type detectors are generally used in the detection of line marks and the detection of pattern edges is also possible.
Transmission type detectors are mainly used in the detection of web edges,and some modeles can detect line marks.

SENSOR

* PS-1000
* PS-260
* PS-261
* PS-270
* PS-711
* PS-800
* PS-300
* PS-350
* PS-400
* PS-520
* PS-45

go top

LPC web guide system actuator

Allows high precision line correction control.

These can be divided into straight "actuators",swiveling "roll-guiders" and rotating "control motors" according to the type of action.We provide the type that is best suited to the customer's specifications for each type.

ACTUATORS

* PD-400
* PD-710
* PD-610
* PD-650
* PD-811
* PD-900
* PD-100
* PD-200
* PDN-400
* PDN-610
* PDN-650
* PDS-400
* PDS-610

ROLLGUIDERS

* PG-10
* PG-50
* PG-80
* PG-100
* PG-110
* PG-701
* PG-400
* PG-301
* PGN-80
* PGN-400
* PGS-400
* MR-10
* MR-50
* MR-60
* MR-65
* MR-100
* MR-210
* MR-250

CONTROL MOTORS

* CM-402F
* CM-412F
